Model Number: P1112ABK
Product Features:
Power Output:
Package Contents:
Product Features:
- Superior in craftsmanship and performance.
- Powerful GaN(gallium nitride) technology offers super-efficiency at current-transferring with low heat generation which also results in a compact and lightweight design.
- This travel charger can be applied globally. It equips foldable US plug and comes with EU, UK and AU adapter for replacement and supports the voltage-input under AC 100~240V, 50~60Hz, 1.7A Max.
- 3 USB-C ports, 1st and 2nd USB-C support up to PD 100W, and the 3rd one up to 20W.
- USB-A port support QC3.0 up to 18W and backward compatible.
- All 4 ports are able to work simultaneously and the power output will automatically process dynamic allocation from 65W to 7.5W. Please be reminded to plug in the high consumption devices first then others.
- Built-in four intelligent protection circuits against overvoltage, overcurrent, overheat and short circuit.
- With LED indicator, clearly express the working status.
Power Output:
- Rated Power: Total 100W Max
- Input: AC: 100-240V AC (50-60Hz) 1.7A Max
- Output:
- Single Connection with USB-C1/USB-C2: Max 100W
- Single Connection with USB-C3: Max 20W
- Single Connection with USB-A: Max 18W
- Dual Connection with USB-C1 & USB-C2: 65W and 30W
- D ual Connection with USB-C1/C2 & USB-C3: 65W and 20W
- Dual Connection with USB-C1/C2 & USB-A: 65W and 18W
- Dual Connection with USB-C3 & USB-A: 7.5W and 7.5W
- Triple Connection with USB-C1, USB-C2, USB-C3: 45W, 30W and 20W
- Triple Connection with USB-C1, USB-C2, USB-A: 45W, 30W and 18W
- Triple Connection with USB-C1/C2, USB-C3, USB-A: 65W, 7.5W and 7.5W
- Quadruple Connection: USB-C1 45W, USB-C2 30W, USB-C3 7.5W and USB-A 7.5W
Hardware&Dimension:
- Product Dimension: 63 x 63 x 30.5 (mm)
- Color: Black
- Upstream: Foldable US Plug
- Downstream:
- 3 x USB-C Female (USB PD)
- 1 x USB-A Female (QC)
Package Contents:
- 1 x 100W TRAVEL TRI GaN
- 1 x User Manual
- Replaceable EU Plug, UK Plug and AU Plug
